Metal Glazed Roof Panel Profile Roll Forming Machine

  • 1 - 1 Sets
    $9,500.00
  • 2 - 2 Sets
    $9,300.00
  • 3 - 19 Sets
    $9,000.00
  • >=20 Sets
    $6,500.00
Model Number:
ZY-2
Power(W):
4+4KW
Report Suspicious Activity
Overview
Quick Details
Warranty:
2 Years
Type:
Tile Forming Machine
Production Capacity:
10-15m/min
Certification:
CE/ISO9001
Condition:
New
Tile Type:
Steel
Use:
Roof
Place of Origin:
Hebei, China
Brand Name:
ZHIYE
Voltage:
380V 50Hz 3phases
Dimension(L*W*H):
6.5*0.9*1.4m
Weight:
depend on design
Metal Sheet Roof And wall Making Machine:
blue and yellow or as client requirement
Sheet Metal Roof Panel Rolling Machinery:
material steel IBR Metal Sheet Forming Line
Sheet Metal Roof Roll Former machinery:
control system:Delta PLC
Sheet Metal Roof Roll Former machine:
power: 4+4kw IBR Metal Sheet Forming Line
Single Layer Roof Sheet Forming Machine:
max carrying capacity: 5000kg
Single Layer Wall Roll Forming Machine:
transmission model: gear and chain
Single Roof Panel Forming Machine:
controlling model: PLC controlling system
Single Roof Sheet Roll Forming Machine:
Material of blades: Cr12 quenched
Corrugated Sheet Roll Forming Machine:
Power supply : hydraulic power
Corrugated Sheet Roll Formers machine:
coil max width: 1250mm
Supply Ability
Supply Ability:
100 Set/Sets per Month China Alibaba Roof Tile Roll Forming Machine Trapezoidal Roof Sh
Packaging & Delivery
Packaging Details
Building Material Red Adjustable Roof Sheet Cold Roll Forming Machine package:nude, the computer controlling part is packed with water proof cloth.
The adjustable roll forming machine packed 20 feet container, it fit for ocean shipping. we have good relationship wih the shipping agent to get good freight price for you and you can also find yourself at your side.
Port
tianjin
Product Description

Metal Glazed Roof Panel Profile Roll Forming Machine Aplication

This Metal Glazed Roof Panel Profile Roll Forming Machine takes GI/PPGI as raw material, through a series steps and can produce the metal roofing sheets.Metal Glazed Roof Panel Profile Roll Forming Machine produce building material so It is usually use for construction. To be more precise that's widely used in various industrial factory ,beauty spot, holiday village building, hotel,exhibition ,easy steel building manufacturing ,and have features such as nice appearance and durable.

Metal Glazed Roof Panel Profile Roll Forming Machine
Metal Glazed Roof Panel Profile Roll Forming Machine
Main motor power
Kw
3
Material expand width
mm
1000,1200,1250
Thickness
mm
0.2~0.8

Main performance parameters
Diameter of principal axis
mm
70-90
Controlling system
PLC
Processing speed
m/min
0-14
Roller discription
Roller station
Rollers
8-20
Roller material
high grade 45#steel; Cr12 quenching
Material of roller
High grade 45# forged steel plated with hard chrome plating
Our main products are Trapezoidal Roof Panel Roll Forming Machine,Glazed Roofing Tile Roll Forming Line,Roof Ridge Cap Production Line,C/u/z Purlin Roller Former Machine,Roller Door Panel Rolling Forming Machine,Floor Decking Panel Rolling Forming Machine,Downpipe Rain Gutter Roll Forming Machine,Light Steel Frame Cold Roll Forming Machine,Double Layer Roof Sheet Roll Forming Machine,Sandwich Panel Wall Roof Roll Forming Machine
Detailed Images
1.Metal Glazed Roof Panel Profile Roll Forming Machine Manual Uncoiler:

Usage: It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand.

Loading capacity: 5T

Inner diameter: 500-508mm
2.Metal Glazed Roof Panel Profile Roll Forming Machine Feeding Table:

Put the raw material (steel plate) through the beach to manufacture and process, it can guarantee that the products are neat. Parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron
3.Metal Glazed Roof Panel Profile Roll Forming Machine Main Roll Forming Machine:

Material of rollers: 45# steel, roller surfaces polishing, hard plating. The polished surface and the heat treatment towards the molds also can keep the molding. Plate surface smooth and not easy to be marked when it is being stamped.


4.Metal Glazed Roof Panel Profile Roll Forming Machine Hydraulic System:

Power: 11KW, Hydraulic oil:46#.

Hydraulic oil into the hydraulic oil tank, the pump drives the cutter machine to begin the cutting job.


Our Service

Our Service

1..Technology R&D
We have R&D centers and innovative designing teams for different kinds of production lines.


2..Quality Control
We have independent QC departments both in the company and factories which strictly control the quality of each process to enable our production lines to reach Chinese National Standards, even International Standards

After Sale Service

3.Warranty period 2 years , after this period , we are willing to give help if customer needs accessory . The real cooperation will not end at the delivery . we believe that satisfied after sale service means a lot.

4..Inspected by the Sellers
After completing the manufacturing and assembling of the equipments, we will test the machines and commissioning in the workshop.
